Model
|
48100
|
48200
|
48300
|
48400
|
|
Cell material
|
Lithium iron phosphate (LFP)
|
|||
|
Nominal voltage
|
51.2V
|
|||
|
Nominal capacity
|
100Ah@0.5C
|
206Ah@0.3C
|
295Ah@0.3C
|
400Ah@0.5C
|
|
Maximum number of modules in series
|
Not supported
|
|||
|
Maximum number of modules in parallel
|
4
|
|||
|
Operating voltage range
|
44V ~ 58.4V
|
|||
|
Nominal energy
|
5.12KWh
|
10.5kWh
|
15kWh
|
20.5kWh
|
|
Usable energy
|
4.864KWh
|
10kWh
|
14.3kWh
|
19.4kWh
|
|
Rated charge / discharge current
|
50A
|
100A
|
100A
|
150A
|
|
Maximum charge / discharge current
|
100A
|
150A
|
150A
|
200A
|
|
Peak charge / discharge current
|
120A(3S)
|
160A
|
210 (1S, 25℃) 过流保护值
|
210A
|
|
Recommended depth of discharge (DoD)
|
95%
|
|||
|
Dimensions (W × H × D)
|
480*645*155mm
|
440*743*232mm
|
530*812.5*235mm
|
530*787*253mm
|
|
Weight
|
48kg
|
100kg
|
125kg
|
143kg
|
|
LCD display
|
|
|||
|
Protection rating
|
IP32
|
|||
|
Charging temperature
|
0℃ ~ +50℃
|
|||
|
Discharge temperature
|
-20℃ ~ +55℃
|
|||
|
Storage temperature
|
0 ~ 45℃
|
|||
|
Relative humidity
|
10% ~ 85%
|
|||
|
Altitude
|
≤3000m
|
|||
|
hermal management method
|
自然冷却
|
|||
|
Installation method
|
Wall-mounted
|
Wall-mounted
|
Floor-standing
|
Floor-standing
|
|
PCS communication method
|
RS485\CAN
|
|||
|
BMS parallel communication
|
RS485
|
|||
|
Remote transmission
|
NA
|
Bluetooth / Wi-Fi (optional)
|
Bluetooth / Wi-Fi (optional)
|
Bluetooth / Wi-Fi (optional)
|
|
Warranty
|
5 年
|
|||
|
Reference standard
|
GBT36276-2023, IEC62619, CE
|
|||
|
Certification standard
|
UN38.3
|
|||
