| Model |
HY-LFPST-24200 |
HY-LFPST-24210 |
HY-LFPST-24330 |
| Battery Type |
LiFePO4 (Lithium Iron Phosphate) |
LiFePO4 (Lithium Iron Phosphate) |
LiFePO4 (Lithium Iron Phosphate) |
| Nominal Voltage |
25.6V |
25.6V |
25.6V |
| Nominal Capacity (Ah) |
135Ah |
165Ah |
230Ah |
| Nominal Energy (Wh) |
3456Wh |
4224Wh |
8448Wh |
| Charge Voltage |
29.2V |
29.2V |
29.2V |
| Recommended Charge Current |
67.5A |
82.5A |
115A |
| Discharge Cut-off Voltage |
20.0V |
20.0V |
20.0V |
| Max Continuous Discharge Current |
135A |
165A |
230A |
| CCA (Cold Cranking Amps) |
1000A @ 10S |
1100A @ 10S |
1300A @ 10S |
| Dimensions (mm) |
510×220×210 |
505×220×220 |
505×285×230 |
| Weight (kg) |
27 |
35 |
47 |
| Operating Temperature Range |
-20°C ~ 60°C |
-20°C ~ 60°C |
-20°C ~ 60°C |
| Operating Humidity Range |
5% ~ 95% |
5% ~ 95% |
5% ~ 95% |
| Housing Material |
ABS |
Sheet Metal |
Sheet Metal |
| Protection Rating |
IP65 |
IP65 |
IP65 |
| Additional Features |
4G Smart Monitoring, Heating Function, GPS Positioning Function |
Product features
Schedule the start of heating
4G intelligent connection, remote intelligent control, intelligent anti-theft
Brand A battery cells, durable and long-lasting
Remote fault diagnosis
Remote one-click start, dual functions for parking and start
Wider operating temperature range
No need for daily maintenance High cost-effectiveness
Safer and more environmentally friendly
